Power Battery PACK Automatic Production Line (AGV)

Power battery PACK automatic production line (AGV) 01 The lower cabinet is automatically online 02 Install the box connector 03 Reserved work space 04 Modules are automatically put into the box 05 Module pre-tightening 06 The module is automatically tightened 07 Install the collection harness 08 Install BDU 09 Soft connection fixed 10 Install the high-voltage wiring harness 11 BMS installation 12 reserved workstations 13 Connect the water cooling pipes 14 Water-cooled air tightness test 15 EOL test 16 DCR Test 1 17 DCR Test 2 18 Paste the sealing strip 19 Automatic upper cover installation 20 Pre-tighten the upper cover 21 The upper cover is automatically tightened 22 reserved workstations 23 The battery pack is offline.

Large Flow Iron Separator（deironing，iron removal，deferrization，removal of Fe）

Large flow iron separator（deironing，iron removal，deferrization，removal of Fe） Features 1-Removal of magnetic impurity content in cathode slurry to improve cell K value 2-High-strength magnetic bar adsorption, to achieve magnetic bar cleaning and reduce cleaning time 3-Add up and down floating design to prevent liquid leakage 4-Independent research and development and design, and in the process and end use of the lithium battery industry, it has achieved a revolutionary breakthrough in its safety and stability.

Pack Mylar into the Shell Machine

Fully automatic loading and unloading, accurate in-position detection and positioning mechanism. Cells and aluminum shells are automatically supplied, equipped with the function of detecting poor incoming materials and automatically adjusting assembly positioning. Vision system detects the external dimensions of cells and aluminum shells to increase assembly accuracy.

Battery Coating Machine

Diolame coating machine Features Fully automatic loading and unloading; Real-time monitoring of data, self-developed software can deliver data with customer MES system; Realize different processes of battery U-shaped pack and ring pack.

Cell Outer Blue Film Dispensing System

Cell outer blue film dispensing system Features The battery (charged battery) gluing function after the square aluminum shell is coated Fully automatic connection equipment.

Square battery cell sorting and packaging system

Square Cell Sorting and Packaging System

Square cell sorting and packaging system Features Square cell sorting.

Square Cell Baler

Square cell baler Features Cell automatic packaging.

Basic parameters	parameter value
Equipment size	401525m
Single line capacity	≥12JPH
Production line yield	≥99%
Production line utilization	≥95%
